An eMTB with the weight of an MTB, starting at 15.5kg! Take the best Cross-Country/Trail platform to date, the Spark 900, top it off with 130mm of travel paired with a 140mm fork, add silent and powerful electric assistance, yet keep its legendary lightweight DNA, and you are ready to ride any trail at Ninos speed.

Specifications

Frame Carbon HMX, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline Fork FOX 34 Float Rhythm Air Grip, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel Shock FOX NUDE 6T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Low Speed Adj. / Custom large Air volume / Reb. Adj., Bearing Hardware / Travel 130-90-Lockout / T165X45mm Rear Derailleur SRAM S1000 Eagle AXS Transmission 12 SpeedWireless Electronic Shift System Shifter SRAM AXS Pod Controller Front Brake Shimano Deore M6120 4 Piston Disc Rear Brake Shimano Deore M6120 4 Piston Disc Rotors front: Shimano SM-RT64 CL 180mmRear: Shimano RT-EM600 CL 180mm Rims Syncros X-30S / 32H / 30mm, Tubeless ready Front Hub Formula CL-811 / 15x110mm Rear Hub Formula CL-148S / 12x148mm Spokes Stainless Black 15G / 1.8mm Front Tyre Schwalbe Wicked Will 29×2.4″ EVO, Super Race / TLE / 67EPI / Addix Speed Soft Rear Tyre Schwalbe Wicked Will 29×2.4″ EVO, Super Race / TLE / 67EPI / Addix Speed Grip Handlebars Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8 / 760mm Stem Syncros DC 2.0, Syncros Cable Integration System, 0 rise / 6061 Alloy / 31.8mm / 1 1/8″ Grips Syncros Performance XC lock-on grips Headset Syncros – Acros Angle adjust & Cable Routing HS System, +-0.6 head angle adjustment, ZS56/28.6 ZS56/40 MTB Remote Lockout SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes Saddle Syncros Tofino 2.0 Regular, CRMO rails Seatpost Syncros Duncan Dropper Post 2.0, 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm Crankset FSA Alloy Chain SRAM CN GX Eagle Transmission Cassette SRAM Eagle XS 1270 Transmission 10-52 Motor TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph Battery TQ Internal 360Wh Display TQ HPR, Bluetooth / ANT+ / Dedicated Smartphone app Charger TQ 100-240V-4A Weight (KG) 17,9

Geometry

S M L XL Stack 615 615 625 638 Reach 416 446 476 501 Headtube Angle 65.5 65.5 65.5 65.5 Headtube Length 110 110 120 135 Seattube Angle 76.8 77 77.2 77.5 Seattube Length 415 440 480 520 Toptube (Effective) 562 589 620 645 Chainstay Length 450 450 450 450 Wheelbase 1176 1206 1240 1270 BB Height 338.5 338.5 338.5 338.5 BB Drop -38.5 38.5 38.5 38.5 Standover 765 767 780 800 Fork Length 540 540 540 540 Stem Length 580 60 70 70 Maximum Seatpost Insertion 150 175 215 255 Crank Length 170 170 175 175
