The strength of a powerlifter, with marathon endurance and the physique of a gymnast. For the mountain biker looking to unlock new zones and ride more terrain than ever, the ALL-NEW Patron eRIDE holsters the cutting edge of full-power moter and battery technology in a package built for singletrack domination. Harness the power. Master the trails.

Specifications

Frame Carbon Main Frame / Alloy SST-CST, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, Bosch Smart System / UDH Interface / 12x148mm with 55mm Chainline, Bosch PowerMore Ready Fork FOX 36 Perf. Air / eMTB+ / Grip / Comp & Reb Adj. / QR Axle 15x110mm axle, 44mm offset / tapered steerer / 150mm travel Shock FOX NUDE 6T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Low Speed Adj. / Custom large Air volume / Reb. Adj., Bearing Hardware / Travel 150-100-Lockout / T185X55mm Rear Derailleur SRAM GX Eagle AXS Transmission 12 SpeedWireless Electronic Shift System Shifter SRAM AXS Pod Controller Front Brake Magura MT7 4 Piston / Bosch ABS Pro Rear Brake Magura MT7 4 Piston Rotors front: Magura MDR-P 220mmRear: Magura MDR-P 203mm Rims Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready Front Hub Formula DC-711 / 15x110mm Rear Hub Formula EHT-1481 / Boost 148x12mm Spokes Stainless Black Front Tyre Maxxis Forekaster 29×2.6″, 120TPI Foldable Bead, EXO / TR Tubeless ready, 3C Maxx Terra Rear Tyre Maxxis Forekaster 29×2.6″, 120TPI Foldable Bead, EXO / TR Tubeless ready, 3C Maxx Terra Handlebars Syncros Hixon 1.5 Alloy 7050, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8 / 780mm Stem Syncros AM 1.5, Syncros Cable Integration System, 4 rise / 7050 Alloy / 31.8mm / 1 1/8″ Grips Syncros Performance XC lock-on grips Headset Syncros – Acros Angle adjust & Cable Routing HS System, Stainless / +-0.6 head angle adjustment, ZS56/28.6 ZS56/40 MTB Remote Lockout SCOTT TracLoc 2 Technology, Suspension & Dropper Remote, 3 modes Saddle Syncros Tofino-E 1.5 Regular, Titanium rails Seatpost Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm, S size 140mm / M size 180mm / L size 180mm / XL size 210mm Crankset SRAM GX Eagle / Alloy Chain SRAM CN GX Eagle Transmission Cassette SRAM CN GX Eagle Transmission Motor Bosch Performance CX, EU: 25kmh / INT: 20mph Battery PowerTube 800Wh Display Bosch System Controller, Mini Remote & Kiox 300 Charger 4A Charger Weight (KG) 24,4

S M L XL Stack 650.5 655.0 664.2 673.3 Reach 428.3 448.3 473.9 503.4 Headtube Angle 64.9 64.9 64.9 64.9 Headtube Length 120 125 135 145 Seattube Angle 76.4 76.3 76.3 76.3 Seattube Length 405 435 470 500 Toptube (Effective) 582.4 607.9 629.7 660.2 Chainstay Length 454 454 454 454 Wheelbase 1222.3 1244.5 1274.2 1308.0 BB Height 348.6 348.6 348.6 348.6 BB Drop -28.4 -28.4 -28.4 -28.5 Standover 719 719 729 732 Stem Length 50 50 50 50 Crank Length 165 165 165 165 Fork Length 584 584 584 584 Max Seatpost Insertion 200 230 265 295 Trail 127.9 127.9 127.9 127.9
